Advantages
- No packing seal or mechanical seal required in the upper drive device reduces maintenance cost.
- Combined screening separate heavy rejects and light rejects effectively, which will improve efficiency.
- Light rejects above the liquid level is spun off by centrifugal force, higher dry degree and less fiber loss.
- Combination of defibering, screening and dehydration, cleaning production, higher fiber yield.
Technical Data
| Model | Capacity(T/D) | Max. Consistency(T/D) | Speed(RPM) | Motor Power(KW) | Inlet Pressure(BAR) | Output Pressure(BAR) | Pressure Drop(BAR) | Flush Water Flowrate(L/min) |
| CS4M | ≤70 | 3.0 | 465 | 85 | 1.4-1.6 | 0.6-0.8 | 0.4-0.8 | 200 |
| CS6M | ≤150 | 3.0 | 420 | 175 | 1.3-1.7 | 0.6-0.8 | 0.4-0.8 | — |
